1. Standard Compliance:
The cable adheres to the IEC 60227 standard, which is an internationally recognized standard for electrical cables and wires set by the International Electrotechnical Commission.
This ensures that the cable meets the global quality and safety requirements for electrical cables, providing reliable performance in various applications.
2. Conductor Specification:
It features an aluminum conductor. Aluminum is a cost-effective material for conductors and is suitable for power transmission where large amounts of current need to be carried.
The 4*240mm2 indicates that there are four conductors, each with a cross-sectional area of 240 square millimeters.
This relatively large cross-sectional area allows the cable to handle high current loads, making it ideal for medium to large-scale power distribution systems.
3. XLPE Insulation:
a. The insulation of the cable is made of Cross-Linked Polyethylene (XLPE). XLPE is a superior insulating material with excellent electrical insulation properties.
It has a high dielectric strength, which means it can effectively prevent the leakage of electrical current and ensure the safe transmission of electricity.
b. XLPE also has good heat resistance. The cable can operate at a normal temperature of up to 90 degrees Celsius, and can withstand short-term high temperatures during short-circuit conditions, ensuring the stability and reliability of the power supply even in abnormal situations.
c. Additionally, XLPE is resistant to moisture, chemicals, and other environmental factors, which helps to extend the service life of the cable in various harsh working environments.
4. Voltage Rating:
The rated voltage of the cable is 0.6/1kv. This means that it is suitable for use in low-voltage power distribution systems, such as in industrial plants, commercial buildings, and residential areas. It can safely transmit electrical power at a voltage within this range, providing stable power supply for various electrical equipment and systems.
5. Application Areas:
Due to its excellent performance and specifications, this cable is widely used in underground power distribution systems, where it is protected from external mechanical damage and environmental impacts.
It is also suitable for use in power stations, construction sites, and other industrial and commercial facilities that require reliable power transmission.
